Cynosure MedLite C6 laser

Medlite C6 Q-Switched Nd:YAG laser by Cynosure

Technical Specifications

Laser Type: Nd YAG and Dye Impregnated Polymers

Operating Parameters:

• EO Q-Switched, Nominal Delivered Energy at end of Articulated Arm with no Handpiece
• 1064 nm – 1.0 Joule
• 532 nm – 400 mJ

Nominal Pulse Energy Density:

• 1064 nm – 12.0 J/cm2 @ 3.0 mm spot size
• 532 nm – 5.0 J/cm2 @ 2.0 mm spot size

Pulse Width: 5-20 ns

Repetition Rate: Single shot, 1 Hz, 2 Hz, 5 Hz, 10 Hz

Spot Size:

• 1064 nm – 3, 4, 6, 8 mm
• 532 nm – 2, 3, 4, 6 mm

Cooling: Closed Cycle Water to Air Heat Exchanger

Input Power: 115 V | 60 Hz | Single Phase | 15 A

Weight: 127 Pounds (58 kg)

Unit Base Dimensions: 28.5″ D x 12″ W x 31.8″ H (44.5″ H with arm)
